1.Megapixels HD CMOS Sensor，support 720p (1280*720)/640*480/320*240/160*120 video resolution.
2.Adopt H.264＆Mjpeg compression format, image very clear and move smoothly suitable for Local, Internet and Cross-platform view.
3.Support TF Card ,max 32GB.
4.Support IR-CUT and color filter change automatically(IR-Cut),no any color difference.
5.Support WIFI function, unique antenna make the wifi signal stronger.
6.Support UPNP function.
7.Infrared LED 30pcs for night vision covers 15-20area, to realize 24 hours monitoring
8.Support smart mobile phone view (android, iphone,windows mobile )
9.Support clients software of Android,IOS,etc.
10.Support video view by other browsers like as IE, Firefox,safari etc.
11.Allow remote viewing video and record from any internet connection
12.Multi-level users management and passwords definition.
13.Support UPNP,DDNS，WPS（You do not need to know the SSID and security keys or passphrases when connecting WPS-enabled devices.）
14.Support multi-view. Long time recording. Video replay etc.
15.Support motion detection, email FTP alarm Motion detection alert via email or upload image to FTP; It also sends alarm info to the alarm server.
16.adopt the TCP/IP network protocols and built-in web server. Users can browse video through IE and other other browsers. Data is transferred through one port; it is easy for user to do the network setting.
17.1,4,9,16,25,36,64，100 multiple video display optional in one screen, support record, alarm, remote playback on records and other management functions.
18.Manufacture provides free multi-camera management software.
Image Capture
Sensor
Mega pixels CMOS sensor
Minimum illumination
IR lights on，0 Lux
Lens
f=4mm
IR_CUT
Support IR and color filter change automatically
Pan/Tilt
Pan Coverage
0°
Tilt Coverage
0°
Assistant
Lighting Control
Auto/manual control
Lighting
30pcs 850nm Infrared lights,15-20m distant
Video and Audio
First Stream Resolution
H.264 720P（1280*720）/640*480/320*240
Second Stream Resolution
Mjpeg 640*480
Compression
H.264/MJPEG
Frame rate
30fps
First Stream Bit rate
512Kbps ~ 4.096Mbps
Second Stream Bit rate
4Mbps－8 Mbps
Image Rotation
Flip / Mirror
Supporting PBC MODE：
Push button configuration (PBC) – an actual push button on the hardware or through a simulated push button in the software
OSD
support
Network
Basic Protocol
TCP/IP、HTTP、SMTP、RTSP、FTP、DHCP、DDNS、UPNP、NTP
Other Protocol
802.11b/g/n
Other Features
Mobile Phone View
Support
Video control
support
Dual way audio
no
Memory
Snap or video into SD card
Motion Detection
yes
Triggered Actions
Email/FTP/SD storage/external alarm/send message to alarm server
User Setting
Three levels
Date/ Time Setting
Support
Upgrade
Upgrade from network
DDNS
A free DDNS provided by manufacturer
Hardware Interface
Ethernet
10Base-T/100base-TX
Physical Index
Weight
1.25kg
Power consumption
<12W
Operating
-20℃~ 50℃
Humidity
10% ~ 80% non-condensing
Software(PC Side)
OS Supported
Microsoft Windows XP/Vista/windows7.
Browser
Internet Explorer6.0 and Above or Compatible Browser, Safari/Firefox etc.
Online visitor
Support 10 visitors at the same time
IP mode
Dynamic IP address, static IP address,; Supporting WPS (Wi-Fi Protected Setup) Client do not need to know the SSID and security keys or passphrases when connecting WPS-enabled devices.
