Model Name

 VS-HSC-32

  Image Device

  1/3 SONY

  Resolution

  420 TVL

  Picture Elements

  PAL:500(H)×582(V); NTSC:510(H)×492(V)

  Min. Illumination

  1.0 Lux /F2.0

  TV System

   PAL/NTSC

  Lens Furnished

   3.7mm Taper Pinhole Lens

  S/N Ratio

   More than 48dB

  Electronic Shutter

   NTSC:1/60~1/100,000, PAL:1/50~1/110,000

  Gamma

   0.45

  White Balance

   Auto

  Gain Control

   Auto

  Sync. System

   Internal

  Video Output

   1 Vp-p / 75 Ohms

  Power Supply

   DC12V±10%

  Operation  Temperature

   -10℃ ~ +50℃ RH95% Max

  Dimension

   ¢83 x 68 mm

  Weight

   200g
